FP2/FP2SHOverview
1 − 8
1.2 Unit Types and Combinations
1.2 Unit Types and Combinations
1.2.1 Line-Up of Backplanes and Units
Option
Product name Product number
Dummy unit AFP2300
Battery Lithium battery (button) AFC8801
atte y
Lithium battery AFP8801
Battery for AFP2209 AFP2806
Terminal block for FP2 I/O unit AFP2800
Set of connector for wire−pressed
terminal cable (2 pieces)
AFP2801
Set of flat cable connector (2 pieces) AFP2802
FP2 CPU FP2SH CPU
SmallS-
RAM
F−ROM
(AFP5208)
EP−ROM
(AFP5209)
SmallS-
RAM
Backplanes H type
11-module type (Basic)
FP2−BP11MH (AFP25011MH)
10-module type (Expansion)
FP2−BP10EH (AFP25010EH)
5-module type
(FP2−BP05)
7-module type
(FP2−BP07)
9-module type
(FP2−BP09)
12-module type
(FP2−BP12)
14-module type
(FP2−BP14)
Backplanes
(for CPU and expan-
sion backplanes)
The 5−module type
backplane can not be
used for expansion.
Standard type
CPU
(FP2−C1)
CPU with
64-point input
(FP2−C1D)
CPU with
S-LINK
(FP2−C1SL)
Standard type:
32k step: FP2−C2L
(AFP2221)
60k step: FP2−C2
(AFP2231)
Small PC card compliant type:
60k step: FP2−C2P
(AFP2235)
120k step: FP2−C3P
(AFP2255)
Power supply units
100 to 240V AC 5A type
(FP2−PSA3)
200V AC 2.5A type
(FP2−PSA2)
100V AC 2.5A type
(FP2−PSA1)
24V DC 5A type
(FP2−PSD2)
Optional memories
FROM FP2−EM4
EPROM FP2−EM5
FP2−EM1
FP2−EM2
FP2−EM3
FP2−EM6
FP2−EM7
For FP2
FROM type IC memory card
(AIC50020)
SRAM type IC
memory card
(AIC52000)
Discontinued
products
Memory unit
ROM socket
(FP2-EM7)
SRAM type IC
memory card
(AFP2209)
Memory unit for FP2SH
Type of memory unit
Part No. Comment
input
function
Clock/
calendar
function
With 16k
expansion
RAM
ROM
socket
FP2−EM1
FP2−EM2
FP2−EM3
FP2−EM6
FP2−EM7
A
A
A
N/A
N/A
A
A
A
N/A
N/A
N/A
A
A
A
N/A
N/A
N/A
A
A
A
A: Available, N/A: Not available
Memory unit for FP2SH
Small PC card for FP2SH
Memory unit F−ROM implemented)
(AFP2208)
