FP2/FP2SHProcedure Until Operation
5 − 4
5.1 Before Turning ON the Power
5.1.2 Procedure Up To Operation
After installing and wiring, perform the operation by following procedure.
Procedure:
1. Power on
1) Before turning on the power, check the items described on the pre-
vious page.
2) Turn on the power and then, check that the power supply unit’s POW-
ER LED and CPU’s PROG. LED are on.
2. Enter the program
1) When using a programming tool, perform the operation “Clear Pro-
gram” before inputting.
2) Enter the program using the programming tool software.
3) Use the programming tool’s “total check function” to check for syntax
errors.
3. Check output wiring
Use the forced I/O function to check the output wiring.
4. Check input wiring
Check the input wiring by using the input display LEDs or the monitor-
ing function of the programming tool.
5. Trial operation
1) Switch the mode selector from PROG. to RUN mode, check the RUN
LED turns on.
2) Check the operation of the program.
6. Edit the program (debug) if necessary
1) If there is an error in the operation, check the program using the moni-
toring function of the programming tool.
2) Correct the program.
7. Save the edited program
We highly recommend to save the created program onto a floppy disk
or hard disk. Printing out is also possible. The program can also be
saved on the ROM.
To Next Page
