FP2/FP2SH Specifications
10 − 5
10.1 Specifications
Type Part number Weight
(Approx.)
Intelligent unit
S-LINK unit FP2−SL2 120g
Intelligent
unit
Multi-wire link unit FP2−MW 110g
ET−LAN unit, ET−LAN2 unit FP2−ET1, FP2−ET2 125g
MEWNET−VE link unit, MEWNET−VE2 link unit FP2−VE, FP2−VE2 125g
Remote I/O Slave Unit FP2−RMS 110g
FNS Unit
FNS Unit Transistor output type FP2−FNS 88g
FNS
Unit
FP−FNS
Bl k
PROFIBUS AFPN−AB6200 31g
FP FNS
Block
Device Net AFPN−AB6201 32g
CAN open AFPN−AB6218 32g
FMU Unit
PROFIBUS FP2−DPV1−M 118g
FMU
Unit
Device Net FP2−DEV−M 118g
CAN open FP2−CAN−M 118g
Expansion cable
FP2−EC 180g
Expansion
cable
FP2−EC2 400g
FP2 Performance Specifications
Item
FP2 CPU
FP2−C1 (AFP2211), FP2−C1D (AFP2212), FP2−C1SL (AFP2214)
Program/control method Relay symbol/cyclic operation
Controllable
I/O points
Basic construction Using Backplanes: Max. 768 points (12 modules)
Using Backplanes H type: Max. 512 points (8 modules)
p
Expanded construction Using Backplanes: Max. 1,600 points (25 modules)
Using Backplanes H type: Max. 2,048 points (32 modules)
Using remote I/O system Max. 2,048 points (using S-LINK or MEWNET-F system)
Program
capacity
Internal memory Approx. 16k steps
capac
it
y
(* Note 1)
Using expansion memory Approx. 32k steps (* Note 2)
Number of
instruc
-
Basic instructions 96 types
i
ns
t
ruc-
tions
High-level instructions 428 types
Operation
speed
(il
Basic instructions From 0.35μs per instruction
speed
(typical
value)
High-level instructions From 0.93μs per instruction
Operation
External input relays (X) 2,048 points (* Note 1)
p
memory
points
for
External output relays (Y) 2,048 points (* Note 1)
points
for
relays
Internal relays (R) 4,048 points (* Note 3)
relays
Timer/counter (T/C) Total 1,024 points (* Note 3)
− Timer: units of 1ms, 10ms, 100ms and 1s
counts up to 32,767 × each unit
− Counter: 1 to 32,767 counts
Link relays (L) 2,048 points (* Notes 3 and 4)
Pulse relays (P) 1,024 points (* Note 3)
Alarm relays (E) Not available
Data registers (DT) 6,000 words (* Note 3)
File registers (FL) 0 to 14,333 words (when expanding: 0 to 30,717 words) (* Note 3)
Link data registers (LD) 256 words (* Notes 3 and 5)
Timer/counter set value
area (SV)
1,024 words
Timer/counter elapsed
value area (EV)
1,024 words
Index registers (I0 to ID) 14 words
next page
