FP2/FP2SHSpecifications
10 − 8
10.1 Specifications
FP2SH Performance Specifications
Item
FP2SH CPU
FP2−C2L (AFP2221), FP2−C2 (AFP2231), FP2−C2P (AFP2235), FP2−C3P
(AFP2255)
Program/control method Relay symbol/cyclic operation
Controllable
I/O points
Basic
construction
Using Backplanes: Max. 768 points (12 modules)
Using Backplanes H type: Max. 512 points (8 modules)
p
Expanded
construction
Using Backplanes: Max. 1,600 points (25 modules)
Using Backplanes H type: Max. 2,048 points (32 modules)
Using remote
I/O system
Max. 8,192 points (using S−LINK or MEWNET-F system)
Program
capacity
Internal memory FP2−C2/FP2−C2P: approx. 60K steps
FP2−C3P: approx. 120K steps
py
Using
expansion
memory unit
——
Number of
instructions
Basic
instructions
95 types
High-level
instructions
434 types
Operation
speed
(t i l
Basic
instructions
From 0.03μs per instruction
p
(typical
value)
High-level
instructions
From 0.06μs per instruction
Operation
memory
it
f
External input
relays (X)
8,192 points (* Note 1)
y
points for
relays
External output
relays (Y)
8,192 points (* Note 1)
Internal relays
(R)
14,192 points (* Note 2)
Timer/counter
(T/C)
Total 3,072 points (* Note 2)
− Timer: units of 1ms, 10ms, 100ms and 1s
counts up to 32,767 × each unit
− Counter: 1 to 32,767 counts
Link relays (L) 10,240 points (* Notes 2 and 3)
Pulse relays (P) 2,048 points (* Note 2)
Alarm relays (E) 2,048 points (* Note 2)
Operation
memory
points
for
Data registers
(DT)
10,240 words (* Note 2)
y
points for
memory
areas
File registers
(FL)
FP2−C2L: 32,765 words
FP2−C2, FP2−C2P, FP2−C3P: 32,765 words × 3 banks (* Note 2)
Link data
registers (LD)
8,448 words (* Notes 2 and 4)
Timer/counter
set value area
(SV)
3,072 words
Timer/counter
elapsed value
area (EV)
3,072 words
Index registers
(I0 to ID)
14 words × 16 banks
