FP2/FP2SHFP2/FP2SH Operation
6 − 22
6.7 FP2SH ROM Operation
6.7.4 Checking the ROM Contents While Using RAM Operation
When the DIP switches on the back of the CPU have been set to the RAM operation side,
the CPU reads the contents of the internal RAM in that state. To check the contents (pro-
grams) of the ROM, use the procedure described below to send the data to the RAM.
Preparation
Set the CPU in the PROG. mode.
Procedure:
1. Select “On
line Edit Mode” on the “Online” menu.
The system goes online, and online monitoring begins automatically.
The
icon on the tool bar can also be used to do this.
2. Select “ROM & RAM service...” on the “Tool” menu.
The “ROM & RAM Service” window opens.
3. The “ROM → RAM” is executed.
Select “ROM → RAM” and click on the “Execute” button.
The contents of the ROM are sent to the internal RAM.
To Next Page
