FP2/FP2SHFP2/FP2SH Operation
6 − 8
6.4 Writing to ROM
6.4 Writing to ROM
6.4.1 Writing to EPROM Using Programming Tool Software
This method entails using programming tool software at the computer to send the
program directly to any commercially available ROM writer and writing the data to
the ROM.
Preparation
Connect the commercially available ROM writer to the computer.
Attach the optional memory EPROM (FP2−EM5) in the commercially available ROM
writer. Read the program with programming tool software.
Commercially available
ROM writer
Procedure:
1. On the “Option” menu, select “Communication Set-
tings”, and set the transmission speed and
communication format that matched that for the ROM
writer.
2. On the “Tool” menu, select “ROM Writer”.
3. Select “Write” and “Serial Port” and click “Execute” but-
ton. The program is copied to the ROM writer.
To Next Page
