Parts and FunctionsFP2/FP2SH
2 51
2.10 Output Units Specifications
2.10.7 64-point Type Transistor (NPN) Output Unit
Specifications
Item Description
Part number FP2Y64T
Insulation method Optical coupler
Rated load voltage 5 to 24V DC
Load voltage range 4.75 to 26.4V DC
Maximum load current 0.1A (at 12 to 24V DC) , 50mA (at 5V DC) (* Note)
Maximum surge current 0.3A
Off state leakage current 1µA or less
On state maximum voltage drop 1V or less (at 6 to 26.4V DC), 0.5V or less (at 6V DC or less)
Response time off on 0.1ms or less
p
on off 0.3ms or less
Internal current consumption
(at 5V DC)
210mA or less
Power supply for driving
it l
iit
Voltage 4.75 to 26.4V DC
pp y
g
internal circuit
Current 250mA or less (at 24V DC)
Surge absorber Zener diode
Fuse ratings None
Common method (Output points per
common)
32 points/common
Operating indicator 32-dot LED display (lit when on, switching)
External connection method Connector (MIL type two 40-pin)
Weight Approx. 120g
Note
The load current will vary depending on the power supply for
driving the internal circuit and the ambient temperature. Adjust
the load current referring to the following range.
32/
89.6
41/
105.8
55/
131
Number of
points per
common which
are simulta-
neous on
Ambient temperature (°C/°F)
Max. load current (mA)
Power supply for driving
internal circuit (V)
64
43
28
26.4V DC
24V DC
50
100
4.75 10.2 26.4
