2.11 I/O Mixed Units Specifications
2.1 1 .2 32−point Type DC Input/32−point Type T ransistor (PNP) Output Unit
Specifications
Item Description
Part number FP2−XY64D2P
Input specifica-
ti
Insulation method Optical coupler
p
p
tions
Rated input voltage 24V DC
Rated input current Approx. 4.3mA (at 24V DC)
Input impedance Approx. 5.6kΩ
Input voltage range 20.4 to 26.4V DC
Min. on voltage/
Min. on current
19.2V/4mA
Max. off voltage/
Max. off current
5.0V/1.5mA
Response time off → on 0.2ms or less
p
on → off 0.3ms or less
Common method (Input points
per common)
32 points/common
Either the positive or negative of the input power supply
can be connected to common terminal.
Output specifica-
ti
Insulation method Optical coupler
p
p
tions
Rated load voltage 5 to 24V DC
Load voltage range 4.75 to 26.4V DC
Maximum load current 0.1A (at 12 to 24V DC), 50mA (at 5V DC) (* Note)
Maximum surge current 0.3A
Off state leakage current 1µA or less
On state maximum voltage drop 1.5V or less (at 6 to 26.4V DC),
0.5V or less (at 6V DC or less)
Response time off → on 0.1ms or less
p
on → off 0.3ms or less
Power supply for
driving
internal
Voltage 4.75 to 26.4V DC
d
r
i
v
i
ng
i
nterna
l
circuit
Current 130mA or less (at 24V DC)
Surge absorber Zener diode
Fuse ratings None
Common method (Output points
per common)
32 points/common
Common specifi-
cations
Internal current consumption (at
5V DC)
150mA or less
caos
Operating indicator 32-dot LED display (lit when on, switching)
External Connection method Connector (two 40-pin)
Weight Approx. 120g
