2.10 Output Units Specifications
2.10.2 6-point Type Relay Output Unit
Specifications
Item Description
Part number FP2−Y6R
Insulation method Optical coupler
Rated control capacity 5A 250V AC (10A/common), 5A 30V DC (10A/common)(* Note)
Min. load: 100mA, 10V (resistor load)
Response time off → on 10ms or less
on → off 8ms or less
Life time Mechanical 20,000,000 operations or more
Electrical 100, 000 operations or more
Internal current consumption
(at 5V DC)
50mA or less
Power supply for driving
Voltage
24V DC 10% (21.6 to 26.4V DC)
internal circuit
Current 70mA or less
Surge absorber None
Relay socket None
Common method (Output points per
common)
2 points/common
Operating indicator 6-dot LED display (lit when on)
External connection method Terminal block (M 3 screw)
Weight Approx. 170g
Note
For each common 1 pin, use at a current capacity of 5A or less.
