FP2/FP2SHOverview
1 − 20
1.4 Programming Tools
1.4.2 Software Environment and Suitable Cable
Standard ladder diagram tool software FPWIN−GR Ver.2
Type of software OS
(Operating system)
Hard disk capacity Product No.
FPWIN GR Ver. 2
English−language
menu
Full type Windows 98
Windows Me
Windows
2000
40MB or more AFPS10520
menu
Upgraded version
Wi
n
d
ows 2000
Windows XP
Windows Vista
AFPS10520R
Note
1) Ver.1.1 must be installed to install the upgrade version.
2) Ver.2.0 can be upgraded to Ver. 2.1 or later free of charge at
our web site (http://panasonic−electric−works.net/ac).
Conforms to IEC61131−3 programming tool software FPWIN−Pro Ver.6
Type of software OS
(Operating system)
Hard disk capacity Product No.
FPWIN GR Ver. 6 English−lan-
guage menu
Windows 2000
Windows XP
Windows Vista
100MB or more AFPS50560
Note
1) The upgrade version is not available for Ver.6.
2) Ver.6.0 can be upgraded to Ver. 6.1 or later free of charge at
our web site (http://panasonic−electric−works.net/ac).
Type of computer and suitable cable
For the connection between a computer (RS232C) and the control unit (RS232C)
D−sub connector cable
PC side connector PLC side connector Specifications Product No.
D−sub 9−pin Mini DIN round 5−pin L type (3 m) AFC8503
p
Mini DIN round 5−pin Straight type (3 m) AFC8503S
Note
A USB/RS232C conversion cable is necessary to connect with a
personal computer without a RS232C port using a PC connection
cable.
