FP2/FP2SHFP2/FP2SH Operation
6 − 32
6.8 FP2SH IC Memory Card Operation (for FP2−C2P/FP2−C3P)
6.8.3 How the IC Memory Card is Operated
Turn off the power supply, and remove the CPU.
Have the IC memory card ready that contains programs already written to it.
Procedure:
1. Set the DIP switches on the back of the CPU for IC
memory card operation (SW2: on, SW4: on).
2. Install the CPU back in its original position on the back-
plane.
If the power supply is switched on in the RUN mode, the
program on the IC memory card called “Autoexec.spg”
is sent to the internal RAM. The program is transferred
at the point when the power supply is turned on.
Note
If the power supply is turned on with the “Autoexec.spg” file on
the IC memory card, all contents of the RAM up to that point are
lost.
