FP2/FP2SHInstallation and Wiring
4 − 32
4.4 Wiring the Connector Type I/O Units
4.4.4 Connecting with Flat Cable Connector
When connecting with a flat cable connector, the relationship between the cable num-
ber and I/O number is shown below.
Correspondence table of cable number and I/O number
Examples for the CN1 group Examples for the CN2 group
Cable
No.
Input
No.
Outp
ut
No.
Cable
No.
Input
No.
Outp
ut
No.
Cable
No.
Input
No.
Outp
ut
No.
Cable
No.
Input
No.
Outp
ut
No.
1 X0 Y0 21 X10 Y10 1 X20 Y20 21 X30 Y30
2 X8 Y8 22 X18 Y18 2 X28 Y28 22 X38 Y38
3 X1 Y1 23 X11 Y11 3 X21 Y21 23 X31 Y31
4 X9 Y9 24 X19 Y19 4 X29 Y29 24 X39 Y39
5 X2 Y2 25 X12 Y12 5 X22 Y22 25 X32 Y32
6 XA YA 26 X1A Y1A 6 X2A Y2A 26 X3A Y3A
7 X3 Y3 27 X13 Y13 7 X23 Y23 27 X33 Y33
8 XB YB 28 X1B Y1B 8 X2B Y2B 28 X3B Y3B
9 X4 Y4 29 X14 Y14 9 X24 Y24 29 X34 Y34
10 XC YC 30 X1C Y1C 10 X2C Y2C 30 X3C Y3C
11 X5 Y5 31 X15 Y15 11 X25 Y25 31 X35 Y35
12 XD YD 32 X1D Y1D 12 X2D Y2D 32 X3D Y3D
13 X6 Y6 33 X16 Y16 13 X26 Y26 33 X36 Y36
14 XE YE 34 X1E Y1E 14 X2E Y2E 34 X3E Y3E
15 X7 Y7 35 X17 Y17 15 X27 Y27 35 X37 Y37
16 XF YF 36 X1F Y1F 16 X2F Y2F 36 X3F Y3F
17 COM − 37 COM − 17 COM − 37 COM −
18 COM − 38 COM − 18 COM − 38 COM −
19 NC + 39 NC + 19 NC + 39 NC +
20 NC + 40 NC + 20 NC + 40 NC +
To Next Page
