FP2/FP2SH Specifications
10 − 7
10.1 Specifications
Notes
1) The practical usable external input and output points are re-
stricted according to the number of the input and output units.
The external output relays (Y) that not used at the output unit
can be used as internal relays.
2) The expansion memory unit (FP2−EM2, FP2−EM3 or FP2−EM6)
is required.
3) Hold or non-hold type can be set using the system registers.
4) Can also be used as internal relays.
5) Can also be used as data registers.
6) The expansion memory unit (FP2−EM1, FP2−EM2 or FP2−EM3)
is required.
7) Precision of calendar timer:
At 0°C/32°F, less than 90-second error per month.
At 25°C/77 °F, less than 40-second error per month.
At 55°C/131°F, less than 98-second error per month.
8) The expansion memory unit (FP2−EM3, FP2−EM6 or FP2−EM7)
is required.
