Panasonic fp2/fp2sh User Manual

OverviewFP2/FP2SH
1 − 9
1.2 Unit Types and Combinations
DA4
Communication
Block
FP2−CB232
FP2−CB422
Communication
Block
FP2−CB485
FNS
FP2−FNS
Communication
Block
PROFIBUS
(AFPN−AB6200)
Communication
Block
DeviceNet
(AFPN−AB6201)
Communication
Block
CANopen
(AFPN−AB6218)
FMU
FP2−DPV1−M
FMU
FP2−DEV−M
FMU
FP2−CAN−M
Input, Output and I/O mixed units
16-point DC input
(FP2−X16D2)
16-point transistor output
NPN type (FP2−Y16T)
16-point transistor output
PNP type (FP2−Y16P)
6-point relay output type
(FP2−Y6R)
16-point relay output type
(FP2−Y16R)
64-point DC input (FP2−X64D2)
64-point transistor output NPN type
(FP2−Y64T)
64-point transistor output PNP type
(FP2−Y64P)
32-point input/ 32-point output
NPN type (FP2−XY64D2T)
32-point input/output (NPN) with on
pulse catch input (FP2−XY64D7T)
32-point input/ 32-point output
PNP type (FP2−XY64D2P)
32-point input/output (PNP) with on
pulse catch input (FP2−XY64D7P)
32-point DC input
(FP2−X32D2)
32-point transistor out-
put NPN type
(FP2−Y32T)
32-point transistor out-
put PNP type
(FP2−Y32P)
Analog input
FP2−AD8VI
Analog output
FP2−DA4
Analog output
FP2−AD8X
RTD input
FP2−RTD
High speed counter
FP2−HSCT(NPN)
FP2−HSCP(PNP)
Pulse I/O
FP2−PXYT(NPN)
FP2−PXYP(PNP)
Positioning
(4−axis)
FP2−PP4
Positioning
(2−axis)
FP2−PP2
Positioning (4−axis)
Multifunction
Transistor FP2−PP41
Line driver FP2−PP42
Positioning (2−axis)
Multifunction
Transistor FP2−PP21
Line driver FP2−PP22
Positioning RTEX
FP2−PN2AN
(2−axis)
FP2−PN4AN
(4−axis)
FP2−PN8AN
(8−axis)
Positioning (4−axis)
(Interpolation)
Transistor FP2−PP4T
Line driver FP2−PP4L
Positioning (2−axis)
(Interpolation)
Transistor FP2−PP2T
Line driver
FP2−PP2L
Serial data
FP2−SDU
C.C.U
FP2−CCU
MCU
FP2−MCU
S-LINK
FP2−SL2
ET−LAN
FP2−ET1
Multi−wire link
FP2−MW
MEWNET−VE link
FP2−VE
Remote I/O Slave
FP2−RMS
MEWNET−VE2 link
FP2−VE2
ET−LAN2
FP2−ET2
