Panasonic fp2/fp2sh User Manual

11-15
FP2/FP2SH/FP10SH
Item
Add-
ress
Name
Default
value
Descriptions
Tool port
setting
414
Baud rate setting for the
tool port
19200 bps
In the FP10SH, when the dip switch
SW1 on the CPU is off, the baud rate
setting is effective.
In the FP2/FP2SH, when the dip
switch SW1 on the rear of the CPU is
off, the baud rate setting is effective.
19200 bps 19200 bps
1200 bps 38400 bps
2400 bps 57600 bps
4800 bps 115200 bps
9600 bps
COM
port
setting
412
Communication method
setting for COM port
FP2: Not
used
UNUSED: COM port is not used.
COMPUTER LINK: computer link
mode (when connecting C-NET)
GENERAL: serial data communication
mode
FP2SH/
FP10SH:
Computer
link
413
Communication format
setting (Common setting
for both computer link
and serial data
communication)
When used for computer
link, the start and end
code settings of format
for MEWTOCOL-COM will
not be effective.
Available PLC: FP2/
FP2SH
Character
bit: 8 bits,
Parity chk:
“With,
odd”
Stop bit:
1 bit,
End code:
CR,
Start
code:
NO STX
Character bit: 7 bits/8 bits
Parity chk: non/with odd/with even
Stop bit: 1 bit/2 bits
End code: CR/CR+LF/NON/ETX
Start code: NO STX/STX
414
Baud rate setting for the
COM port
Available PLC: FP2/
FP2SH
19200 bps
19200 bps 19200 bps
1200 bps 38400 bps
2400 bps 57600 bps
4800 bps 115200 bps
9600 bps
415
Unit number setting for
COM port
Available PLC: FP2/
FP2SH
1 1 to 99 (unit No. 1 to 99)
416
Modem compatibility
setting for COM port
Available PLC: FP2/
FP2SH
Modem
disabled
Modem enabled/Modem disabled
When connecting a modem, set the
unit number to 1 with system register
415.
General
commu-
nication
setting
417
Starting address setting
for received buffer of
serial data
communication mode
(data register number)
0
FP2SH/FP10SH:
0 to 10240
FP2: 0 to 5999
For details about
its usage, refer to
the F144 (TRNS)/
P144 (PTRNS)
instructions.
418
Capacity setting for
received buffer of serial
data communication
mode (word number)
1024 0 to 1024
