Panasonic fp2/fp2sh - Page 340

11-72
Num-
ber
Name Boolean
Operand
Description
Steps
FP0/FP-e
FP0R
FP
Σ
FP-X
FP2
FP2SH/FP10SH
F174
Pulse output
(Selectable data
table control
operation )
SP0H
S, n
Outputs the pulses from the
specified channel according to
the
data table specified by S.
5
F175
Pulse output
(Linear
interpolation)
SPSH S, n
Pulses are output from channel,
in accordance with the
designated data table, so that
the path to the target position
forms a straight line.
5
F176
Pulse output
(Circular
interpolation)
SPCH
S, n
Pulses are output from channel,
in accordance with the
designated data table, so that
the path to the target position
forms an arc.
5
F177 Pulse output
(Home return)
HOME S, n Performs the home return
according to the specified data
table.
7
F178
Input pulse
measurement
(No. of pulses,
cycle for input
pulses)
PLSM
S1, S2, D
Measures the number of pulses
and cycle of pulses to be input
to the high-speed counter of the
specified channel.
5
