Philips IntelliVue MP70 Service Manual

Installing Remote Devices 7 Installation Instructions
139
Installing Interface Boards
If you add interface boards to your monitor, you must insert them into the device according to the
combinations in the following table:
“-” This board is assumed to not be required for the configuration
“X” This board cannot be assigned in this configuration
Installing Remote Devices
This section provides instructions for Philips products. Installation instructions for devices not sold by
Philips must be provided by the device manufacturer.
Mounting the Remote Display (M8031A)
The Philips M8031A XGA Color Flatscreen Display is designed for use with the MP60/MP70
monitor as a slave display. A bracket is supplied with the display to connect it to a variety of Philips
mounting devices.
A - Removing the desktop stand:
1 Remove the covers from the screws on the back of the flatscreen display
2 Remove the four screws from the back cover of the display and detach the cover.
3 Remove the four screws from the desktop stand and detach the desktop stand.
B - Attaching the bracket:
1 Place the bracket on the back of the display with the slits facing upwards.
2 Attach the bracket to the display with four M4x8 screws.
3 Attach the desired mounting device to bracket.
NOTE Do not mount the display in a position where liquid could spill onto it.
I/O Board Possible Configurations
Name Compatibility Rules A B C D E F G H I
MSL/LAN Must be in slot 01 01 01 01 01 01 01 01 01 01
PS/2 Device
Interface
Must be in slot 02 if used for the integrated Speed
Point
02 02 02 02 02 02 ---
Remote Device
Interface
Must be in slot 03 if supporting the Remote Alarm
Device
03 03 03 - --03 03 -
Parallel Printer
Interface
Preferred slot 03 04 - -0303 - 02 02 03
Nurse Call
Relay (Flexible)
Must be in slots 02, 03, or 04 X04-04-0404 - 02
MIB/RS232 Preferred slot is 04 XX 04 X 04 X X0404
