Philips IntelliVue MP70 Service Manual

7 Installation Instructions Installing Remote Devices
148
Connections
Connect the cable to the Remote Extension Device as shown in the photograph.
Figure 25 Remote Extension Device Connections
Cabling
The connection at the monitor should look like on the photograph . Connect the cable at both the
extension device and the monitor
Remote Extension Device Rear View
Remote Extension Device Connectors Remote Extension Device with Cable connected
