Philips IntelliVue MP70 Service Manual

Tools Required 5 Repair and Disassembly
101
Removing the Video Board
1 Remove the three screws and unplug the video board connector from the main board.
2 Pull up the board and slide it out
Removing the Main Board
1 Unplug the cable to the SpeedPoint (if installed).
Captive Screw
Captive Screw (Closeup)
