Remote Device Site Requirements 8 Site Preparation
163
Remote Alarm Devices
Space Requirements
Size (W x D x H)
62mm x 125mm x 63 mm (2.4” x 5” x 2.5”)
Weight
< 300 g (< 0.7 lb)
Cabling Options and Conduit Size Requirements
The following table describes the cabling options for the Remote Alarm Device M8025A.
Table 9 M8025A Remote Alarm Device Cables
Remote Extension Device
Space Requirements
Size (W x D x H):
103mm x 139mm x 63 mm (4” x 5.5” x 2.5”)
Weight:
< 400 g (< 0.9 lb)
Cabling Options and Conduit Size Requirements
The following table describes the cabling options for the M8026A Remote Extension Device.
Product Option
Number
Part Number Description Conduit Max. Bend Angle
M8022A #HF2 M8086-61003 1.5m Monitor to Remote
Device
not yet available. not yet available.
M8022A #HF3 M8086-61004 3m Monitor to Remote
Device
M8022A #HF6 M8086-61005 10m Monitor to Remote
Device
a
M8022A #HF7 M8086-61006 15m Monitor to Remote
Device
a
M8022A #HF9 M8086-61007 25m Monitor to Remote
Device
a
Both ends are terminated with straight MDR connectors.
a
Built on demand.
