7 Installation Instructions Installing Remote Devices
146
Remote Alarm Devices
Mounting
The mounting devices for the Remote Alarm Device are the same as for the Remote Extension Device.
See Remote Extension Device for details.
Connections
Figure 24 Remote Alarm Device Connector
Remote Alarm Device Rear View
Remote Alarm Device Connector
Remote Alarm Device with Cable connected
