Philips IntelliVue MP70 Service Manual

Installing Remote Devices 7 Installation Instructions
143
Figure 21 Attaching the Philips - BIS Flexible Measurement Server Mount
Figure 22 Attaching the BIS Engine to Mount
Mounting the FMS
A universal clamp for vertical rail or pole solutions ships with each FMS.
Connections
The cable specifications and part numbers for through wall solutions of the M8048A and M3001A are
described in the Site Preparation section of this manual.
M4 x 8mm PHMS
Mounting Bracket
