9 Anesthetic Gas Module Troubleshooting the Anesthetic Gas Module
208
The fifth flow chart also continues from the third, from point D “Disappearing Waves”:
Figure 49 Troubleshooting - Disappearing Waves
Problem
not fixed
Disappearing waves in
warmup mode.
Wait if it also occurs in
normal mode.
Disconnect exhaust tubing if
available.
Perform flowrate check and
pump test which is provided
in the PM kit. I f pump test
failes, replace pump, if flow
check fails read just and
calibrate flowrates.
Keep unit running for >90 min.
Take care that the Gas Analyzer is
not configured to go into standby
during that time. If standby
configuration has to be altered,
switch it back again afterwards.
Check
Gas Analyzer
Calibration
and Diagnostic
window and follow troubleshooting
tables for reported errors.
D
DONE
DONE
DONE
Problem not
fixed
Problem
fixed
Problem
fixed
Yes No
To Next Page
