Philips IntelliVue MP70 Service Manual

Troubleshooting the Anesthetic Gas Module 9 Anesthetic Gas Module
211
GA ZERO FAILED Purge Flow out of tolerance.
No flow calibration after flow
adjustments
Occlusion during zero calibration.
Solenoid 1 defective.
Measured ambient pressure does not
match with configured altitude in
ACMS Service Mode (tolerance is +/-
60 mmHg).
IR measurement head problem.
Adjust purge flow and calibrate flow.
Repeat zero calibration.
Perform flow calibration
Remove occlusion.
Replace solenoid 1.
Verify correct altitude setting /
pressure Cal value.
If necessary, adjust it.
Check IR head and replace it if
necessary.
O
2
ZERO FAILED O
2
new zero constants out of range. Tro u b l e s h o o t O
2
sensor and replace
it if necessary.
AGENT IDENT
ZERO FAILED
Solenoid 2 defective
Agent-ID problem.
Replace solenoid 2.
Troubleshoot Agent-ID and replace it
if necessary.
O
2
EQUIP MALF O
2
span failed.
O
2
is built in, but set to digital 45%.
Check O
2
span calibration. If it fails,
troubleshoot span calibration/ O
2
sensor and replace it if necessary.
If O
2
value is set to digital “45%” in
Service Mode, replace the O
2
sensor.
AGENT IDENT
MALF
Serious Agent-ID problem. Check Agent-ID and replace it if
necessary.
XXX MEAS
DISTURBED
(XXX: N
2
O, CO
2
,
agent or O
2
)
Minor transient IR head problem
(Minor transient O
2
sensor problem
if XXX = O
2
)
If it lasts only for a few seconds and
clears itself, NO ACTION
REQUIRED.
If it doesn't clear itself, troubleshoot
IR head/ O
2
sensor and replace it if
necessary.
INOP Possible Problem/Cause Corrective action
