Philips IntelliVue MP70 Service Manual

9 Anesthetic Gas Module Troubleshooting the Anesthetic Gas Module
214
Span calibration
shows
Failed (for
O
2
, N
2
O, CO
2
,
agent).
Zero calibration failed
for the indicated
channel.
Follow corrective actions for failed Zero
calibration described above.
Agent selection or
calibration values
(CalValue) incorrect
Check for proper selection of Agent and
calibration values .
Flowrate problem.
Check the flowrate.
Leakage problem. Perform leakage check. Check integrity of
tubing and replace if necessary.
Wrong gas applied.
Check the label on the gas canister.
Calibration reservoir bag
empty or calibration gas
canister empty.
Check that there is enough gas available.
Measurement assembly
problem.
Check the Gas Analyzer Diagnosticwindow for
a Measurement assembly problem. If a problem
is flagged, follow corrective actions as described
in the troubleshooting tables. After that, or if no
problem was flagged, return to the Gas Analyzer
Calibration window. If the failed status is still
shown against Span Calibration, repeat the
Span calibration. After that, perform a Zero
calibration.
O
2
Span calibration
shows
Failed.
O
2
sensor problem. Check O
2
sensor problem as described above.
Symptom Possible Cause Corrective Action
