Philips IntelliVue MP70 Service Manual

Troubleshooting Guide 4 Troubleshooting
73
INOP BAD SERVER
LINK is issued
Unexpected data detected on MSL Check cable and power cycle the
monitor
An FMS or MMS with an
incompatible software revision is
connected to the monitor.
Connect FMS or MMS with
compatible software revsion
Communication between the
components not functioning
Check software versions and
model number of devices for
compatibility
INOP Message
SERVERLINK MALF is
displayed, audible
indicator: a beep every two
seconds
The hardware for communicating
with the Multi-Measurement Server
is faulty.
Check MSL cable, replace if
necessary.
Check MSL I/O board. Replace if
necessary
Check FMS or MMS connector
board. Replace if necessary.
A measurement supported
by a server does not come
up on the monitor
Label conflict A parameter label from this
measurement is already in use in
the monitor. Check the conflict
window to select the
measurement.
Prompt message “To o
many <label> modules
connected” is issued
There are more modules of the type
<label> connected than supported
by the software
Remove the unsupported module
or use the lebel manager
application in the monitor to
disable the module.
The ECG Out/ Marker In
function does not funcion
Hardware problem Check MSL cable
Check ECG Out Hardware in
the monitor
Check the MSL connector in the
measurement server
Symptoms Possible Causes of Failure Failure Isolation and Remedy
