C 2.2 Assembly and electrical installation
Checklist for assembly and electrical installation of the RFC 4072S
Device type / equipment identification
Version:
HW/FW
HW/FW (iSPNS 3000)
Date
Editor Test engineer
Comment
No
.
Requirement Ye s Comment
1 Has assembly and electrical installation been carried out according to
the specifications of the planning phase?
2 Has assembly and electrical installation been carried out according to
the specifications in the user manual for the RFC 4072S?
3 Has assembly and electrical installation been carried out according to
the specifications of the applicable standards and the PROFINET Instal-
lation Guideline for Cabling and Assembly?
4 Has the power supply for the device and direct I/Os been installed
according to the specifications for protective extra-low voltage in accor-
dance with PELV according to EN 60204-1 (including safe isolation with
PELV voltage according to EN 50178/VDE 0160)?
5 Have measures been taken to prevent simple tampering (e.g., control
cabinet can be locked, PLCnext Engineer access rights, etc.)? If so,
what are they?
1 ______________________________________________________
2 ______________________________________________________
3 ______________________________________________________
4 ______________________________________________________
5 ______________________________________________________
6 ______________________________________________________
7 ______________________________________________________
8 ______________________________________________________
9 ______________________________________________________
10 _____________________________________________________
Date Signature (editor)
Date Signature (test engineer)
