Overview
1
13
Polyend Tracker+ Manual
Out Line In Mic MIDI Out MIDI In Micro SD
USB Power
On / Off
Switch
Reset
Switch
USB Power Input
USB-C to USB-A Cable Supplied
3.5mm TRS Audio
Stereo Input
Stereo audio output also serves as headphone out.
3.5mm MIDI
Input & Output
Micro SD Card Slot.
Pins face down.
16GB Micro SD Card Supplied
Stereo Out. 3.5mm Male Stereo
TRS Jack to 2 x 6.3mm TR Mono
Female adapter supplied.
Micro SD Card to USB-A
adapter supplied.
Output also supports
headphones.
Supply is 5V, 1A so can use
the supplied mains to USB or a
battery power bank.
3.5mm Jack to 5 Pin MIDI
adapter (type B) supplied
1.2 Hardware Overview
282 mm
207 mm
33 mm
