8.11 Audio Over USB
The Tracker+ can send and receive audio over a USB connection. This will
send / receive 12 stereo channels to / from a connected device. Mono
channels can also be used. For example between a DAW and Tracker+.
The USB Audio option is set in the USB conguration menu. Any
compatible device connected to the USB connection will be able to access
the audio channels from Tracker+.
Master Output Preview & Metronome
Note that previewing samples from the SD card in the sample loader will
also send the audio to the USB master output. Metronome is also sent to
the USB master output channel.
Pair Outputs
Description
1 1 & 2 Master Output
2 3 & 4
Track 1 Stereo Audio Output
3 5 & 6
Track 2 Stereo Audio Output
4 7 & 8
Track 3 Stereo Audio Output
5 9 & 10
Track 4 Stereo Audio Output
6 11 & 12
Track 5 Stereo Audio Output
7 13 & 14
Track 6 Stereo Audio Output
8 15 & 16
Track 7 Stereo Audio Output
9 17 & 18
Track 8 Stereo Audio Output
10 19 & 20
Reverb Stereo Audio Output
11 21 & 22
Delay Stereo Audio Output
12 23 & 24 Reserved
13 25 & 26 Reserved
14 27 & 28 Reserved
Pair Inputs
Description
1 1 & 2 Main
