Polyend Tracker+ Manual
NOTES
Audio
8
8.4 FM Radio
Tracker+ has a built in FM Radio. This can be used for sampling and
capturing various static or radio signals. Be aware of copyright when
sampling radio especially if considering to release a commercial track.
Source
Radio
Radio Freq
92.2MHz
Gain
5
Monitor
On
Record
Level
On
Off
Line In
Radio
Mic LG
Mic HG
Sample Recorder 0m:00s P1.008
Monitor audio to out
Sample Recorder
Hosts the FM Radio Tuner
Tuning
Manual tuning with (Jog) when selecting
[Radio Freq]. The [Left] and [Right] to
scan frequencies to ne auto tune.
Source
Select the Radio as the
audio input to the sampler.
Gain
Adjustment for boosting
the signal level
Level
Visual indicator of radio
volume level.
Out Line In Mic MIDI Out MIDI In Micro SD
USB
Any cable plugged into the Audio Out jack will act as an antenna for the FM Radio.
Recording of audio can be initiated using the [Record] screen button. Also can be
triggered on this page directly by the [Rec] button
