273
Polyend Tracker+ Manual
NOTES
Master Limiter Page
Accessed via the Master page 1/3 and selected from the screen buttons.
The behaviour of the limiter as extreme or subtle can be set in the ‘Cong’
menu options.
Setting a limiter is an iterative process. Set up the source and fast attack
and release then make small incremental adjustments while playing the
song, starting with threshold. Once an appropriate gain reduction is
reached tweak the attack and gain to further shape the sound.
Option Range Description
Limiter Att 0.001 - 1.000s
Envelope attack time which controls the limiter
behaviour as the limiter kicks in.
Limiter Rls 0.001 - 1.000s
Envelope release time which controls the
limiter behaviour as the limiter drops out.
Limiter Thr -Inf dB to 0dB
The threshold level at which gain reduction
and hence limiting is applied. Source is based
on the audio source - Main or Sidechain.
Gain Reduce
Visual, real time indicator of gain reduction
being applied. Does not offer any parameter
settings - indication only.
Sidechain
Disable, Track
1-8, Line In L R
Selects the audio signal used to trigger
limiting. The normal state is disabled which
uses the main audio. Alternatively individual
tracks or line in L or R can be selected.
Master Limiter Settings.
LimiterAtt
0.369s
LimiterThr
0.00 dB
Gain Reduce Sidechain
Disable
LimiterRls
0.001s
Back
Master Limiter 0m:00s P3.002
Disable
Track 1
Track 4
Track 8
Track 2
Track 5
Line in L
Track 3
Track 7
Track 6
Line in R
Attack
Envelope attack time as the
limiter kicks in.
Gain Reduction
Visible indicator which shows the
gain reduction applied in real time
Sidechain
Sets the audio source used for
triggering gain reduction.
Release
Envelope release time as the
limiter is released
Threshold
Audio level at which the limiter will
kick in and apply gain reduction
Master Effects
10
To Next Page
