Polyend Tracker+ Manual
NOTES
MIDI
11
▌ CREATING A MIDI CC OUTPUT STEP
1. Ensure the Cong > MIDI settings are set to send MIDI.
2. Press [Pattern] to select the Pattern Mode page.
3. Select the target step to edit. Use [Up], [Down] or Turn (Jog) to scroll
top to bottom. Press [Left], [Right] to select a track. Example Row 1 of
Track 1. The step should be highlighted with the green bounding box.
4. Press [Rec] to switch to recording mode. The step bounding box will
turn red and allow editing of the step.
5. Hold [Instrument] + Turn (Jog) to select a MIDI instrument from the 51
to 61 part of the list. Each one will represent a MIDI channel where the
step messages will be transmitted. The Instrument will be indicated with
an ‘M’ in the instrument slot for the step. Example M01.
6. Hold [FX1] or [FX2] + Turn (Jog) to set a CC for the step. This will be
one of the 6 options a-f. The selected option will show as a lower case
letter in the step FX slot. Example: a MIDI CC A.
7. With the FX selected, Turn (Jog) to set it’s CC value. A series of steps
could for example be lled with a ramp up of values. This can be
changed later. Example: Set to 50.
8. Press [Instrument Parameters] to select the MIDI conguration.
9. Select a CC Slot that matches the FX selection - Example, Press [CC
A], 3
rd
Screen button. Any other CC A - CC F can be selected to match
up the the FX setting.
10. Press [Up] or [Down] or Turn (Jog) to scroll the CC parameter lists.
Highlight with the bounding box the CC number to assign. This would
typically be based on the MIDI CC conguration on a receiving device.
Example: CC 74 is Filter Cutoff on Elektron’s Digitakt.
11. In this example, CC Number 74 will transmit a CC value of 50 over MIDI
Channel 1 when the selected step is triggered.
