Radioddity Extended manual for Radioddity DB25-D, DB40-D & GD-88 v3.0
© Radioddity 2023 page 108 of 252
keypad → press the [OK]-key to confirm → ‘Set OK!’ pops up on the screen
and returns to the previous level.
• Upload Path → press the [Select]-key to display the current Upload Path
→ rotate the [ENC] knob or use the [▲/▼]-keys to position the cursor
within the input field → input the desired Upload Path using the numeric
keypad of the Speaker-Microphone → press the [OK]-key to confirm →
‘Set OK!’ pops up on the screen and returns to the previous level.
• Upload Text → press the [Select]-key to display the current Upload Text
→ rotate the [ENC] knob or use the [▲/▼]-keys to position the cursor
within the input field → input the desired Upload Text using the numeric
keypad of the Speaker-Microphone → press the [OK]-key to confirm →
‘Set OK!’ pops up on the screen and returns to the previous level.
(3) DMR APRS → press the [Select]-key to change the parameters for digital
APRS → rotate the [ENC] knob or use the [▲/▼]-keys to choose the desired
parameter → press the [Select]-key to select one of the following options :
• APRS Message → press the [Select]-key to display the list of received APRS
messages → rotate the [ENC] knob or use the [▲/▼]-keys to choose the
received message → press the [Select]-key to display the full APRS data
(date, time, longitude, latitude, altitude, speed) that had been received →
press the [Back]-key to return to the previous level.
Notes: If yet no APRS message had been received, ‘Commsg empty’ pops up
on the screen and returns to the previous level.
• Delete APRS Msg → ‘Are you sure?’ pops up on the screen → press the
[OK]-key to confirm deletion or press the [Back]-key to cancel deletion →
return back to previous level.
(4) Timer → press the [Select]-key to select the interval for regular APRS beacon
transmissions → Rotate the [ENC] knob or use the [▲/▼]-keys to choose in
30s intervals between OFF, 30s and up to 7650s and press the [OK]-key to
confirm → ‘Set OK!’ pops up on the screen and the radio returns to the
previous level.
(5) Beacon → press the [Select]-key to change the location source to be used
for the beacon transmission → rotate the [ENC] knob or use the [▲/▼]-keys
to choose the desired source between Preset Beacon and GPS Beacon →
press the [OK]-key to confirm your selection -> ‘Set OK!’ pops up on the
screen and returns to the previous level.
Notes: If an APRS reporting channel is assigned to the currently selected channel,
the APRS icon will be shown in the upper line of the display.
