Radioddity Extended manual for Radioddity DB25-D, DB40-D & GD-88 v3.0
© Radioddity 2023 page 75 of 252
10.1.3 Manual Dial
1. Press the preset [Contacts]-key to access the contact
or
1. Access the menu, press the [Menu]-key and rotate the [ENC] knob or use the
[▲/▼]-keys to select Contacts and press the [Select]-key to enter.
2. Rotate the [ENC] knob or use the [▲/▼]-keys to select the Manual Dial, press
the [Select]-key to enter the interface for keying in the ID.
3. Input the ID using the numeric keypad of the Speaker-Microphone.
(1) Press the [PTT]-key to initiate a call;
(2) Press the [OK]-key and Rotate the [ENC] knob or use the [▲/▼]-keys to
make following options:
• Application → press the [Select]-key → Rotate the [ENC] knob or use the
[▲/▼]-keys to choose either Radio Check, Call Alert, Remote
Mon.(Monitor), Radio Disable or Radio Enable → press the [Select]-key to
send→ ‘OK’ or ‘Fail’ text pops up on the screen → press the [Back]-key to
return to the previous level.
• SendMsg → press the [Select]-key to Edit a SMS → rotate the [ENC] knob
or use the [▲/▼]-keys to choose either SendMsg (Send Message),
lnsertComMsg (Insert Common Message), Save or ExitEditor → press the
[Select]-key to confirm the selected option → return to the previous level.
10.1.4 Ham Contacts
The Radioddity DB25-D, DB40-D and GD-88 can permanently store up to 300.000
HAM contacts within its internal memory.
1. Access the menu, press the [Menu]-key and rotate the [ENC] knob or use the
[▲/▼]-keys to select Contacts and press the [Select]-key to enter.
2. Rotate the [ENC] knob or use the [▲/▼]-keys to select the Ham Private
Contacts, press the [Select]-key to enter the Ham Private Call Contacts List.
3. Choose the desired private contact by rotating the [ENC] knob, the selected
contact ID number will display at the top left of the screen and the serial No of
the contact displays at the upper right.
or
Long press and hold the [MENU]-key for 3 seconds, a dialogue window pops
up.
