Radioddity Extended manual for Radioddity DB25-D, DB40-D & GD-88 v3.0
© Radioddity 2023 page 30 of 252
5.1.5 Connect Speaker Microphone
1. Please insert the provided speaker microphone to the Mic jack on the left side of
the radio to allow voice communication. Push in the connector until you hear a click
sound from the locating plate in place.
To Next Page
