Chapter 2: Analyzer Description ABL77 Service Manual
Module Descriptions, Continued
Battery charger
The external battery charger is for use with the ABL77 analyzer only. It provides
the source of AC power to the system when plugged into an active electrical socket
(see Figure 2-8).
Figure 2-8
Battery pack
The battery pack is for use with the ABL77. It provides battery power to the
analyzer when AC power is not available or not desired (see Figure 2-9).
Figure 2-9
Continued on next page
2-20 Rev. F
