ABL77 Service Manual Chapter 3: Troubleshooting
Reference Table, Continued
Error # Message Interpretation Corrective Action
1710 Internal query failed The patient query found no
matches within the
analyzer's database
Check the data input for
accuracy
1711 Connection terminated by
user
The external query was
cancelled by the user
Check the network load for
excessive delays
1712 No connection license
available
The connection license has
not been acquired
Contact the Radiometer
Sales Representative
1713 Wrong RAML version There is an incompatible
RAML version being used
in the Radiance
communication
Review the RAML version
and contact the appropriate
Radiance representative to
install a compatible version.
1800 System Errors
1801 Analyzer has been locked The analyzer is in a locked
condition
The system can be unlocked
either on the analyzer
(Options / Data
Communications /
Analyzer Lock) or if
connected to Radiance the
system can be unlocked
within Radiance (see
Analyzer Control).
3000 Input Errors
3001 Input error The value(s) input are
beyond the acceptable input
range.
Re-enter values within the
acceptable input range.
3002 Invalid password Password entered was not
found in the User List
Re-enter password. If
problem persists, review
password list and add
password as appropriate.
3003 Sensor cassette model is
incompatible with the
analyzer parameter
configuration.
A sensor cassette is being
installed with a parameter
configuration incompatible
with the analyzer's allowable
parameters.
Install the correct model of
sensor cassette, matching it
with the analyzer
configuration.
3004 Data Bits can not be set to 5
while the Stop bits is set to
2.
Under Communication
Setup, only certain
combinations of data bits
and stop bits can be selected.
Select the proper
combination of data bits to
stop bits
Continued on next page
3-25
