Rexroth IndraDrive Fusing and Selecting the Mains Contactor 13-5
DOK-INDRV*-SYSTEM*****-PR02-EN-P
Device Mains
choke
Mains
input
contin.
current
I
L,cont
Min. nominal fuse
current of characteristic
Autom.
circuit-
breaker
Power
circuit-
breaker
Min. line
cross
section@
Ta40°
Recom-
mended
mains
contactor
Max.
allowed
switch-
off
delay
[A] eff
@ P
DC
cont
[A] [A] [A] [A]
(setting
value)
[mm²]
([AWG])
Typ [ms]
Properties
gR gL tripping
charact.
C
HMV01.1
E
HNL01.1
W0030 without 26 -- 35 32 26 6 (10) integrated -
W0030 with 43 -- 50 50 43 6 (10) integrated -
W0075 without 64 -- 80 -- 64 25 (4) integrated -
W0075 with 107 -- 125 -- 107 35 (2) integrated -
W0120 without 103 -- 125 -- 103 35 (2) integrated -
W0120 with 170 -- 200 -- 170 95 (000) integrated -
HMV01.1
R
HNL01.1
W0018 with 22 -- 35 32 22 4 (10) integrated -
W0045 with 54 -- 63 63 54 16 (6) integrated -
W0065 with 78 -- 100 -- 78 35 (2) integrated -
tbd: in preparation
Fig. 13-2: Fusing and selection of mains contactor 3AC480V
