Capacitance Data for Power Cables
The Rexroth motor cables of the RKL line have the capacitances listed
below. The values refer to the sum of the single capacitances of power
strands 1, 2 and 3 against the overall shield.
Cable type of non-
assembled cable
Nom. cross section
in [mm²]
Symbol Unit Value
INK 653 1,0 C
Y_K typ
nF/m 0,6
INK 650 1,5 C
Y_K typ
nF/m 0,8
INK 602 2,5 C
Y_K typ
nF/m 0,7
INK 603 4 C
Y_K typ
nF/m tbd
INK 604 6 C
Y_K typ
nF/m 0,8
INK 605 10 C
Y_K typ
nF/m 1,0
INK 606 16 C
Y_K typ
nF/m 1,2
INK 607 25 C
Y_K typ
nF/m 1,1
INK 667 35 C
Y_K typ
nF/m tbd
INK 668 50 C
Y_K typ
nF/m tbd
Fig. 19-2: Capacitance values of power cables
Note: Approximate calculation is allowed with the following values:
• 1 nF/m for cross sections of 1 mm² to 6 mm²
• 1.2 nF/m for cross sections of 10 mm² to 50 mm²
