TRAY HEATER (OPTIONAL PAPER TRAY UNIT)
B291/B295/B296/B297 SM
1-70
6. Install four harness clamps [A].
7. Route the harness [B] and connect it to the harness [C] and heater harness [D].
B004I203.WMF
[A]
[B]
[C]
[D]
