DEVELOPMENT
B291/B295/B296/B297 6-60 SM
6.9 DEVELOPMENT
6.9.1 OVERVIEW
1 Drum 5 Mixing Auger
2 Development Roller 6 Development Filter
3 Paddle Roller 7 Doctor Blade
4 TD Sensor
B195D939.WMF
1
2
3
4
5
6
7
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA
