IMAGE TRANSFER AND PAPER SEPARATION
B291/B295/B296/B297 6-88 SM
Currents applied to leading edge, image areas - by-pass feed
Transfer current can also be adjusted for the leading edge and the image area, and
for by-pass feed. The timing for starting to apply leading edge current, for the
switchover from leading edge current to image area current, and for switching off at
the trailing edge can also be changed.
The table below lists the SP modes you can use to adjust these settings.
SP2-301 Transfer Current Adjustment
Image Areas SP2-301-1 1st Side of Paper
SP2-301-2 2nd Side of Paper
SP2-301-4 By-pass Feed (45 PPM)
SP2-301-6 By-pass Feed (35 PPM)
Leading Edge Areas SP2-301-3 Leading Edge
SP2-301-5 Leading Edge By-pass Feed (35 PPM)
SP2-301-7 Leading Edge By-pass Feed (45 PPM)
SP2-911 Transfer Current Timing
Timing SP2-911-1 On Timing (at leading edge)
SP2-911-2
Switch Timing (from leading edge to image
area current
SP2-911-3 Off Timing (at trailing edge)
