PAPER FEED
SM 3-57 B291/B295/B296/B297
Replacement
Adjustment
3.14.10 IDLE ROLLER DUST BLADE
1. Open the duplex unit and right door.
2. Detach the dust blade [A].
3. Spread some paper on a flat surface and tap the dust blade gently to remove
paper dust collected in its dust box.
B195R986.WMF
[A]
