DUPLEX UNIT
SM 6-79 B291/B295/B296/B297
Detailed
Descriptions
6.13 DUPLEX UNIT
6.13.1 OVERVIEW
1 Entrance sensor 4 Upper transport roller
2 Inverter gate 5 Lower transport roller
3 Inverter roller 6 Exit sensor
B195D961.WMF
1
2
3
4
5
6
