DIP SWITCHES
SM 5-133 B291/B295/B296/B297
Service
Tables
5.7 DIP SWITCHES
Controller: DIP SW1
DIP SW No. ON OFF
1 ROM Boot SD Card Boot
2~7 Keep at “OFF”
8 Keep at "ON"
I/O Board: DIP SW101
DIP SW No. Function ON OFF
1 Copy Speed 35 cpm (180 mm/s) 45 cpm (230 mm/s)
2 Jam Detection
(see Note)
Jam Detection Off On
3 --- --- Keep at "OFF".
4 Print Output for
Debugging
--- Keep at "OFF".
5 SC Detection SC Detection Off SC Detection On
JPN NA EUR Taiwan Asia Korea
6
OFF ON OFF ON ON OFF
7
OFF OFF ON OFF ON ON
8
Destination
OFF OFF OFF ON OFF ON
NOTE: Disabling jam detection is effective only for the main machine (not for the
options).
