Ricoh B291 - Cleaning Mechanism

IMAGE FUSING AND PAPER EXIT
B291/B295/B296/B297 6-94 SM
6.15.7 CLEANING MECHANISM
The cleaning roller [A], in constant contact with the pressure roller [B], collects
toner and paper dust from the surface of the pressure roller.
Because the cleaning roller is metal, it can collect adhering matter better than the
pressure roller, which is coated with Teflon.
B195D983A.WMF
[A]
[B]
