Ricoh B291 - Lower Right Cover

PAPER FEED
B291/B295/B296/B297 3-48 SM
3.14.2 LOWER RIGHT COVER
1. Duplex unit (! 3.4)
2. By-pass tray (!3.6)
3. LCT (if installed)
4. Lower right cover [A] (! x5)
5. Vertical transport cover [B]
NOTE: Push the cover completely to the left and then press in on the right tab
to release the peg from the hole.
B195R957.WMF
[A]
[B]
