BY-PASS TRAY
B291/B295/B296/B297 6-76 SM
6.12 BY-PASS TRAY
6.12.1 OVERVIEW
1 Paper feed roller
2 Paper end sensor
3 Pick-up roller
4 By-pass tray
5 Separation roller
B195D956.WMF
1
2
3
4
5
