Ricoh B291 - Image Transfer and Paper Separation; Overview

IMAGE TRANSFER AND PAPER SEPARATION
SM 6-83 B291/B295/B296/B297
Detailed
Descriptions
6.14 IMAGE TRANSFER AND PAPER SEPARATION
6.14.1 OVERVIEW
1 Transfer belt 6 OPC
2 Drive roller 7 Pick-off pawls
3 Transfer belt cleaning blade 8 ID sensor
4 Transfer roller 9 Contact lever
5 Idle roller 10 Transfer belt contact clutch/cam
B195D966.WMF
1
2
3
4
5
8
7
6
9
10
