RIGHT UPPER COVER
SM 3-5 B291/B295/B296/B297
Replacement
Adjustment
3.5 RIGHT UPPER COVER
NOTE: Work carefully to avoid damaging the development roller.
• Duplex unit (! 3.4)
• Transfer belt unit (! 3.13.1)
• Remove the upper right cover [A]
# (! x1)
$ Loop fastener
% (" x1)
& (# x1, Bushing x1)
B195R904.WMF
[A]
#
$
%
&
